Mracking Heavy Duty Mold Rack System Injection Mold Storage Racks

1 / 5

Mracking Heavy Duty Mold Rack System Injection Mold Storage Racks

Send Inquiry

Product Description

Mould Rack:

It can be adjusted at will;
A pulley and hand-drive block are equipped, so it's convenient for accessing to moulds;
Several moulds can be stored in each drawer, which is helpful to maintain, manage and seek moulds.

Standards Size	Layer	Loading Weight	Bearing	Upright(mm)	Thickness of Board(mm)
*L3100D600H2000*	4	1000kg/drawer	Model 6403	100404	2.0

Technical Specifications
Product	Mold Rack
Material	High-Quality Channel Steel
Size	L3100D600H2000
Color	Green (Can be customized to any color)
Loading Capacity	1000KG/drawer
Surface Treatment	Powder coated
Packing	Air bubble

Category	Specifications Details
Feature	• Easy to remove the shelf boards, vertical spaces are adjustable. • Each group has pulley and handy-lift hoist block, easy storage and unloading of molds, ensuring quality with positioning. • Each section can store several sets of molds, convenient for maintenance, management and locating of molds, not occupying space.
Technological	• The post adopts 10# channel steel, diagonal brace of post is 2525 square meters. • Rack of backing plate is 5050 angle iron, board size of backing plate is 2mm iron plate. • Sliding chute is made of folding 4mm iron plate. • Bearing capacity: 800-1000kg/backing plates.
Material	High-quality cold rolled steel Q235
Color	Standard color is green. It can be customized to any color.
Packaging Term	Foam, wooden case as you need of the drawer mould racks.
Delivery Time	Within 15 days delivery goods.

Production Steps

Professional Design Service Group

Storage Hold Area For Raw Materials

All-automatic Cold Rolling Line

Spraying Coating Line

Stamping Area(Bracket)

Goods Packaging Area(Upright & Beam)

Install drawing 1

Color As You Request

Packaging & Shipping

Company Information

We are a professional company specializing in R&D, production, selling and installation of warehouse shelves and related equipment. Our company has strong strength and reputation with advanced production equipment, production technology and perfect after-sales service, in order to meet all kinds of customers' demands for designing.

Our main products are including: light duty rack, medium duty rack, heavy duty rack, mezzanine floor, cantilever rack, drive-in rack, mobile rack, drawer type mold rack, wire mesh container, logistics carts and related equipment. We constantly pursue product development and application with the spirit of "striving for excellence, honesty is first", and try to reach the aim that "to get the largest storage volume in the limited space", perfectly and reasonably designing for products with high quality and standards.

Our Factory

Our Workshop

Our Warehouse

Finished Product Area

Product Categories

Warehouse Storage System

Pallet Racking System

Mezzanine Floor

Drive-in Pallet Rack 1

Mould Rack

Warehouse Equipment

Supermarket Shelf 1

Cantilever Rack

Wire Container

Warehouse Rack & Shelf

Frequently Asked Questions

1. Are you a factory or trading company?

We are a factory.

2. Where is your factory located? How can I visit there?

Our factory is located in Guangdong Province, China. You can fly to the airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

3. What is the material of your products?

The material is Q235 Cold rolled steel. We can also choose material as customers' requirement.

4. How can I get some samples?

We are honored to offer you samples.

5. How does your factory do regarding quality control?

Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has ISO9001, SGS authentication.

6. What is the standard delivery time for the products?

Standard delivery is within 15 days for delivery of goods.
