Mracking Low MOQ Medium Duty Rack 4 Layers of Beams Freely Adjustable Tire Height for Industrial Warehousing Storage Solution

Product Description

Medium Duty Rack

Medium Duty Rack

Medium duty rack belongs to warehouse storage racking systems. It can be adjusted by each 50mm, and the load capacity can reach 200~500kg. The beam is "P" type beam, whose height matches with that of the layer board.

Standard Sizes

Standards Size Layer Loading Weight Beam (mm) Upright (mm) Thickness of Board (mm)
L2000*D600*H2000 4 200~300kg/layer 60*40*1.2 60*50*1.2 0.5
L2000*D600*H2000 4 400~500kg/layer 60*40*1.5 60*50*1.5 0.7

Product Specifications

Product Name Medium Duty Rack/Shelf
Material High-Quality Q235 Cold-Rolled Steel
Loading Capacity 200~500kg/level
Thickness Upright: 60*40*1.0, 1.2, 1.5mm; Beam: 60*40/80*40*1.0, 1.2, 1.5mm; Steel: 0.5, 0.6, 0.7mm
Color Upright: Blue, Beam: Orange, Steel: Gray white. (Customized colors available)
Surface Treatment Electrostatic Spray Surface
Packing Term Air bubble, Carton, Wooden Case
Warranty 10 Years
Certification SGS
  • Long span shelving rack is very convenient for installation.
  • The adjustment distance of steel layers is 50mm for multiple usages. It consists of vertical columns, layer plates, corner pieces, pins, special bolts, and plastic footing.
  • The surface is electrostatically sprayed and the color is selectable. It has good ability of corrosion protection and rust protection.
  • It is widely used in families, stores, supermarkets, company storages, and public institutions. It is the most updated product.

Beam Loading Capacity & Size

Beam Loading Capacity & Size

Detailed Images

Medium Duty Rack Detail
Medium Duty Rack Specifications
Size L2000*D600*H2000mm, Loading: 300kg/layer, Layer: 4 levels.
Material Upright: 60*50*1.0, Beam: 60*40*1.2, Steel: 0.5mm
Color Upright is blue, beam and steel is gray white.
Packaging Term Air bubble
Surface Treatment Powder Coating
Beam & Upright Connect
Beam & Upright Connect
Diagonal & horizontal bracing Installed
Diagonal & Horizontal Bracing Installed
Steel Board Section
Steel Board Section
Detailed Image 1
Detailed Image 2
Detailed Image 3
Detailed Image 4

Product Overviews

Product Overview 1
Product Overview 2
Product Overview 3

Hot Sale Products

Heavy Duty Pallet Racking
Heavy Duty Pallet Racking
Medium Duty Rack
Medium Duty Rack
Mould Rack
Mould Rack
Cantilever Rack
Cantilever Rack
Mezzanine Floor
Mezzanine Floor
Wire Mesh Container
Wire Mesh Container
Racking Solutions

Frequently Asked Questions (FAQ)

1. Q: Are you a manufacturing or trading company?
A: We are a professional racking manufacturer.
2. Q: What is the material of the rack?
A: Our material is Q235B cold rolled steel.
3. Q: What is the delivery time?
A: Less than 15 workdays in general. It also depends on the order quantity and shelving design.
4. Q: What is the term of payment?
A: 30% T/T down payment and 70% T/T before delivery.
5. Q: How can I get a quick quotation on my racking project?
A: For a quick quotation, please let us know the following information:
1). The size of rack: Length * Depth * Height.
2). Layers per set.
3). Load capacity per beam layer.
4). Racking quantity.
6. Q: What is the manner of packaging?
A: In general, racks are packed with air bubble film. Other packing like wooden cases are available based on customers' requirements.
