H Beam Steel Mezzanine Platform Layout
H Beam Steel Mezzanine Platform Structure

H beam steel mezzanine platform adopts H-type steel and cross beam as the major supporting for the steel panel. Usually we use the steel panel or MDF panel for the mezzanine floor, there are also with staircase and guardrail. Match with the cargolift for the efficiency.

It is suitable for the higher warehouse, large loading capacity, longer span and large storage, it will be full use of the space, one warehouse used as two warehouse. Widely be used for the electronics products, hardware, communication and printing, etc.

Specifications
Specification Details
Raw-Material High-Quality Q235 Cold rolled steel
Color Upright frame is blue, Beam is orange, can be customized.
Height Customized
Wide/Depth Customized
Length Customized
Loading Capacity 200~5000kg per sqm
Treatment Surface Powder coated
Packing Term Air bubble, Wooden Case, etc.
Connection & Assembly Details
Upright & Main Beam Connection
Both of them are H-steel. Its loading capacity is high and span is long. The major beams are connected by connector piece in each side. It will make the beams more stable.
Upright & Main Beam Connect Details
Support Beam & Main Beam Connection
They are connected with the hanging piece. And the hanging piece is welded on the main beam. So the major beam is more stable.
Support Beam & Main Beam Connect Details
Steel Panel & Guardrail Connection
Steel panel and support beam are connected with hooks. It is very stable. The guardrail hangs on the main beam without holes on the beam. So there is no bad influence on the beam.
Steel Panel & Guardrail Connect Details
Detailed Images
Detailed Mezzanine Construction
Mezzanine Decking View
Mezzanine Technical Diagram
Detailed Component View 1 Detailed Component View 2 Detailed Component View 3
Structural Details Left Structural Details Right
Additional System Overview
Upright Support Base
Under Mezzanine Storage Space
Product Overviews
Overall System View 1 Overall System View 2 Overall System View 3
Hot Sale Products
Heavy Duty Pallet Racking
Heavy Duty Pallet Racking
Medium Duty Rack
Medium Duty Rack
Mould Rack
Mould Rack
Cantilever Rack
Cantilever Rack
Mezzanine Floor
Mezzanine Floor
Wire Mesh Container
Wire Mesh Container
Project Case Study 1 Project Case Study 2
Frequently Asked Questions
Q Are you a manufacturing or trading company?
We are a professional racking manufacturer.
Q What is the material of the rack?
Our material is Q235B cold rolled steel.
Q What is the general delivery time?
Less than 15 workdays in general. It also depends on the order quantity and shelving design.
Q What are your terms of payment?
30% T/T down payment and 70% T/T before delivery.
Q How can I get a quick quotation for my racking project?
For a quick quotation, please provide the following details:
1). The size of rack (Length * Depth * Height).
2). Layers per set.
3). Load capacity per beam layer.
4). Racking quantity.
Q Are samples available?
We accept to send you free samples with freight collect.
